Ultrasonic Packing Machine
>
Automatic Bag Sealing Auger Powder Filling Machine 30-40bag/min

Automatic Bag Sealing Auger Powder Filling Machine 30-40bag/min

Brand Name: Penglai
Model Number: PL-300
MOQ: 1set
Price: 5000-8000usd
Payment Terms: T/T,Western Union,MoneyGram
Supply Ability: 100sets/month
Detail Information
Place of Origin:
China
Certification:
CE certifications
Product Name:
Ultrasonic Powder Packing Machine
Model:
PL-300
Voltage:
220V 50Hz/2kw
Control System:
PLC Control
Dosing Method:
Screw Type
Bag Size:
W50-140mm;L50-Limitless
Speed:
30-50bags Per Minute
Weight:
300kg
Packaging Details:
wooden case
Supply Ability:
100sets/month
Highlight:

Automatic Auger Powder Filling Machine

,

Automatic Bag Sealing Machine 40bag/min

,

30bag/min Auger Powder Filling Machine

Product Description

washing powder packing machine coffee packing machine powder capsule filling machine



Application
This machine is suitable for medical, heath care, food, daily chemical and other industries, such as Chinesemedicine aranules, Chinese herbal
medicine granules, wormwood velvet, marinade packs, foot bath packs, activatedcarbon,desiccant qranules, sachets, coffee beans, bamboo
charcoal adsorbents, high Potassium manga manganateparticles,diatomaceous earth particles, etc.

Equipment performance
1. It is composed of loading hopper, distributor, automatic cold sealing and cutting part, and control box as a whole
2.It is easy to operate, good in quality, safe and durable
3. chinese and Enalish display screen control system, only need to set the reauired parameters (filling amount, bag lenath,etc.) in the
displayable setting unit, and the control system wil automaically optimize and match each action to achieve packaging speed
4.Excellent electronic color code control system can automatically and accurately track the cursor on the packaging film,so that the bag can
obtain a complete and beautiful icon
5.The cuting knife is equipped with a control gear function, and you can choose to cut two or more bags at a time. The automatic packaging
machine can automatically complete the measurement, bag making, filing, sealing, cutting, counting,printing, etc. during the packaging
process. Work
6.Stepping motor control, high precision, no need to adjust other parts to change the length of the bag, and accurate.Roller type sealing, the
bag length can be adjusted arbitrarily and infinitely long
7.The contact area between the bag pulling wheel and the ultrasonic vibrator is smal, and the impact force is small, so
8. the damage to the ultrasonic wave is small, and the service life of the ultrasonic wave is longer
9. The wrapping paper part adopts a self-weight motor pressing paper feeding structure, the feeding length of the wrapping paper is
doubled, and the bag is made with a smooth edge
10. The sealing form is ultrasonic cold sealing, which is suitable for packaging materials such as non-woven fabrics, nylonfilm, DuPont paper,
etc., and the sealing is neat, perfect and firm.

Parameter
model PL-300
measuring range 1-50g
dose range turntable measuring cup/screw feeder
voltage AC220V/50Hz/2KW
speed 30-40bag/min
bag type bag seal/side seal
dimension 1850*1250*1900mm
weight 300kg
Product description
Automatic Bag Sealing Auger Powder Filling Machine 30-40bag/min 0

Automatic Bag Sealing Auger Powder Filling Machine 30-40bag/min 1
Automatic Bag Sealing Auger Powder Filling Machine 30-40bag/min 2
Automatic Bag Sealing Auger Powder Filling Machine 30-40bag/min 3
Automatic Bag Sealing Auger Powder Filling Machine 30-40bag/min 4
Automatic Bag Sealing Auger Powder Filling Machine 30-40bag/min 5

Sample bags
Automatic Bag Sealing Auger Powder Filling Machine 30-40bag/min 6
Automatic Bag Sealing Auger Powder Filling Machine 30-40bag/min 7
Automatic Bag Sealing Auger Powder Filling Machine 30-40bag/min 8
Automatic Bag Sealing Auger Powder Filling Machine 30-40bag/min 9
Automatic Bag Sealing Auger Powder Filling Machine 30-40bag/min 10
Automatic Bag Sealing Auger Powder Filling Machine 30-40bag/min 11
Automatic Bag Sealing Auger Powder Filling Machine 30-40bag/min 12
