| Brand Name: | PL |
| Model Number: | PL220QY/QF/QK |
| MOQ: | 1 |
| Price: | USD3000-6000/unit |
| Payment Terms: | Western Union |
| Supply Ability: | 500units in a month |
Automatic Juice Shampoo Liquid Chili Paste Vinegar Ketchup Sauce Mayonnaise Honey Oliver Oil Packaging Packing Filling Machine
This fully-automatic PLC-controlled irregular pouch (doypack) machine is built for tricky-shaped sachets of granules or powders. Servo-screw dosing delivers 1-50 ml repeatable accuracy; film width up to 130 mm, pouch W 15-55 mm & L 40-160 mm stepless adjustable. Full SUS304/316 steel, GMP compliant. Ready for date printer, hole punch and zipper applicator. Quick-change moulds let you jump between pouch styles in minutes and keep 30-50 ppm steady, perfect for premium food, pharma and cosmetic samples.
| Packaging Material | Paper, Plastic, Wood |
| Packaging Type | Bags, Film, Pouch, Stand-up Pouch, Foil, Belt |
| Application | Beverage, Chemical, Commodity, Food, Machinery & Hardware |
| Driven Type | Pneumatic |
| Warranty | 1 Year |
| Voltage | 220V |
| Function | FILLING, Labeling, Sealing, SLITTING, Wrapping |
| Automatic Grade | Automatic |
| Core Components | motor, Pressure vessel, Pump, PLC, Gear, Bearing, Engine, Gearbox |
| After-sales Service | Video technical support, Online support, Engineers available to service machinery overseas |
| Product Name | Liquid packing machine |
| Filling Method | Piston pump |
| Bag Shape | 3 or 4 side sealed/Stick bag |
| Bag Size | L40-150mm W15-120mm |
| Capacity | 0-200ml/bag |
| Speed | 30-50bags/min |
| Control Style | PLC control + English screen |
| Material | Stainless steel |
| Voltage | 220v/50HZ |
| Power | 1.2Kw |
| Weight | 200KG |
| Dimension(L*W*H) | 650*600*1600mm |
